Raleigh Centros Crossbar Electric Hybrid Bike 2022
The Centros Crossbar Electric Hybrid Bike is Raleigh's most advanced e-Bike offering. It combines a sleek look with reliable components and a powerful Bosch Active Line Plus motor and 500Wh battery. This Bosch system provides a maximum of 270% of your pedalling power and has a huge range of up to 135 miles, so you can explore further for less effort and, most importantly, spin up climbs with ease. There are a number of modes to choose from, from zero to maximum assistance, the assistance is provided up to 15.5mph/25kph, and a large-screened Intuvia display makes it easy to make selections and monitor performance. The bike is also super comfortable, with 63mm of travel in the fork to damp vibrations when the terrain turns rough.
The 10-speed drivetrain offers precise and smooth shifting and hydraulic Tektro brakes are included so you can stop fast when required, in all conditions. The wheels are robust and the Mitus tyres are supplied in a wide, bump-absorbing 42mm, and deliver top puncture protection alongside added visibility thanks to reflective strips on the sidewalls. Ready for touring and longer adventures, the Centros is supplied with a front light, mudguards and a rear carrier with an integrated rear light.
Highlights
- 500Wh fully-integrated battery allows you to ride for up to an impressive 135 miles on a single charge and integrates seamlessly into the frame giving the e-bike a sleek finish
- Lightweight motor from Bosch performs over 1,000 measures a second and provides a maximum power output of up to 270% of your pedal power
- The Bosch Intuvia display is quick and easy to use and the central positioning and clear, large screen allow the rider to easily monitor performance throughout a ride
- 10-speed drivetrain
- Tektro hydraulic disc brakes
- Includes a front and rear light, mudguards and a rear carrier
Battery Specification
- Range: 135 miles / 215km
- Battery Power: 500Wh
- Charge Time: 4.5 hours
Technical Specification
| Frame | Raleigh alloy AL6061, crossbar |
| Fork | Suntour Nex, 63mm travel |
| Headset | Low stack, semi-integrated |
| Bottom Bracket | Bosch integrated in motor |
| Stem | Raleigh-approved aluminium adjustable |
| Handlebar | Raleigh Comfort XLC, black |
| Grips | Raleigh Comfort |
| Front Brake | Tektro T285 Hydraulic Disc Brake, 180mm rotor |
| Rear Brake | Tektro T285 Hydraulic Disc Brake, 180mm rotor |
| Brake Levers | Tektro T285 |
| Rear Derailleur | Shimano Deore, 10-speed |
| Shift Levers | Bosch Intuvia Controller |
| Chain | KMC 10-speed |
| Cassette | Shimano 10-speed, 11-34t |
| Crankset | Raleigh Alloy Bosch |
| Front Wheel | Raleigh-approved alloy double wall, 36-hole, disc |
| Rear Wheel | Raleigh-approved alloy double wall, 36-hole, disc |
| Front Tyre | Mitas 700C x 42 with reflective stripe and double duty puncture protection, clincher |
| Rear Tyre | Mitas 700C x 42 with reflective stripe and double duty puncture protection, clincher |
| Saddle | Selle Royal Milo + |
| Seatpost | Raleigh-approved, aluminium |
| Pedals | Raleigh-approved Comfort with anti-slip |
| Accessories | Bosch Speed Sensor / Trelock front light / SKS full mudguards with cable guide / Racktime alloy rack with integrated light |
| Rider and Cargo Weight Limit | 120kg |
| Manufacturer Claimed Weight | 23kg |
| Range | 135 miles / 215km |
| Motor | Bosch Active Line Plus |
| Ui/Remote | Bosch Intuvia multifunctional display with operation unit and push assistance / Bosch Intuvia display holder |
| Battery | Bosch Power Tube 500Wh - 36V |
| Electric assisted speed limit | 15.5 mph / 25 km/h |
Raleigh Centros Crossbar Electric Hybrid Bike Sizing
