Orbea Occam M10 Mountain Bike 2020

★★★★★ ★★★★★
(0)
£4,399.00

From only £164.96 per month

0% APR Representative. T&Cs Apply.

Select a colour and size to view stock availability

Find My Size
Orbea
Occam M10 Mountain Bike 2020

We're sorry, but unfortunately, we're unable to ship this item to your country

Product ID: 1240642

Why buy your bike from Sigma Sports?

sigma sports expert advice
Expert Advice

Don't hesitate to reach out to us. It's our goal to answer all of your questions and offer the best advice from our experts. We’ll be happy to answer any questions you may have. Contact us now or visit us in-store.

sigma sports built checked tuned and tested
Built, Checked, Tuned and Tested

All our bikes are fully built by our Cytech qualified mechanics. To find out more, see the Built, Checked, Tuned and Tested section below to see how we'll deliver your bike.

Free Bike Delivery

We offer FREE DELIVERY of your bike to your home or place of work. Once you've placed your order, our Customer Care team will be in contact to offer a convenient delivery date of your choice.

sigma sports free 30 day bike insurance
Free 30-Day Bike Insurance

We've partnered with PedalSure to offer you 30-DAYS FREE bike insurance on new bikes over £400. Visit our Cycle Insurance page to learn more and claim.

Orbea Occam M10 Mountain Bike 2020

The Orbea Occam M10 Mountain Bike is a fiend on the trails, and something of a jack of all trades - handling varied climbs with efficiency and enabling you to maintain speed with ease thanks to larger, fast-rolling 29" DT-Swiss wheels. The 140mm travel Orbea Monocoque Race (OMR) frame combines high modulus and high strength fibres for a light, responsive frame that delivers true performance and reliability, even when you're putting it through its paces, and Orbea's own dropper seatpost comes in handy on steep sections.

This is a nimble bike with a roomy cockpit that maintains balance as you shift and adjust on the go, whilst the slacker head angle keeps you stable and lower bottom bracket enables you to breeze round corners with confidence and control. This frame features a single-sided frame strut that allows access to a mid-ride drink from the left side, serving to support and stiffen a high-stress area. Internal cable routing maintains a clean aesthetic on this all-rounder, and the FOX 34 Float Factory suspension fork features 140mm travel for smooth riding and superior compression damping when flowing over roots and undulating terrain.

12-speed Shimano XT components make for snappy shifting and a comprehensive range of gears, so you're never grinding up a ramp pining for that extra click, and the single front 32t chainring assures easy maintenance. Shimano XT M8120 hydraulic disc brakes are quick to react, providing certain stopping power that'll have you bombing down descents with confidence and precision.

Highlights

  • 140mm of suspension from the Fox 34 Float Factory fork and Fox DPX2 Factory rear shock
  • Shimano XT M8100 1x drivetrain
  • OMR carbon frame
  • 12-speed 10-51t cassette
  • DT-Swiss XM-1650 29" wheelset
  • Orbea OC2 Dropper seatpost

Technical Specification

Frame Orbea Occam OMR 2020 140mm travel 29" C-Boost 12x148mm
Rear Shock FOX DPX2 Factory 3-Position Adjust Evol Kashima custom tune 210x50mm
Fork FOX 34 Float Factory 140 FIT4 3-Pos-Adj QR15x110 Kashima with 140mm of travel
Headset Acros Alloy 1-1/8 - 1-1/2" integrated
Stem Race Face Aeffect R 35mm interface
Handlebar Race Face Next R 35 20mm rise, 780mm width
Front Brake Shimano XT M8120 hydraulic disc
Rear Brake Shimano XT M8120 hydraulic disc
Brake Levers Shimano XT M8120
Rear Derailleur Shimano XT M8100 SGS Shadow Plus 12-speed
Shift Levers Shimano XT M8100 I-Spec EV
Cassette Shimano XT M8100 10-51t 12-speed
Crankset Shimano XT M8100 32t
Front Wheel DT Swiss XM-1650 Spline 30c TLR CL, Boost
Rear Wheel DT Swiss XM-1650 Spline 30c TLR CL, Star Ratchet, Boost
Front Tyre Maxxis High Roller II 2.50" FB 60 TPI Dual Exo TR clincher
Rear Tyre Maxxis Rekon 2.40" FB 60 TPI Dual Exo TR clincher
Saddle Fizik Taiga Kium rail
Seatpost Orbea OC2 Dropper 31.6mm
Pedals Available to be purchased separately

Built, Checked, Tuned and Tested

All our bikes are fully built, checked, tuned and tested by our Cytech qualified mechanics and then securely packaged, ready for delivery. All you have to do is add the pedals (if specified), attach the handlebars to the stem and tighten them following the included detailed instructions or by watching our video and using the provided FREE tools. Visit our Bike Assembly page to see how you assemble your new bike once you receive it.

All bikes collected from our shop, are built, tested and ready to ride.

Please note, occasionally, manufacturers may change the specification without notice. Bicycles do not come with pedals unless otherwise specified. We do not install accessories to bikes, including mudguards.


Orbea Occam M10 Mountain Bike 2020 Sizing
