Description
Trek Fuel EX 7 NX Eagle 29" Mountain Bike 2020
Trek’s Fuel EX 7 NX Eagle 29" Mountain Bike is a versatile and capable machine that is a great one-bike-to-do-it-all option. The 130mm aluminium frame features Knock Block protection that prevents the fork crown from hitting the downtube, and a Mino Link chip in the rocker that changes the geometry between a steeper and a slacker setting. The air-sprung RockShox 35 Gold has the Motion Control damper to control the 140mm of travel, making a great all-mountain platform.
Both the Bontrager Line Comp 30 and the XR4 Team Issue tyres are tubeless-ready for greater compliance and improved puncture resistance. The 11-50 cassette and 30 tooth chainring of the SRAM NX Eagle drivetrain provide a huge range of ratios for all eventualities whilst the Shimano MT400 hydraulic disc brakes are reliable and powerful, even in wet or muddy conditions. Finishing off the package is a TranzX JD-YSP18 dropper seatpost which enables the saddle to be lowered or raised on the move to help with steep decents or technical trails.
Highlights
- Trek Alpha Platinum Aluminium frame with tapered head tube, Knock Block, Control Freak internal routing, downtube guard, ISCG 05, magnesium rocker link, Mino Link and Boost
- FOX Performance FLOAT EVOL rear shock with RE:aktiv Thru Shaft 3-position damper, tuned by Trek Suspension Lab
- RockShox 35 Gold DebonAir spring fork with Motion Control damper, 140mm travel
- SRAM NX Eagle, 12-speed drivetrain
- Shimano MT400 hydraulic disc brakes
- Bontrager Line Comp 30, Tubeless Ready wheels
- TranzX JD-YSP18 dropper seatpost
Technical Specification
| Frame | Trek Alpha Platinum Aluminium, tapered head tube, Knock Block, Control Freak internal routing, downtube guard, ISCG 05, magnesium rocker link, Mino Link, ABP, Boost148, 130 mm travel |
| Fork | RockShox 35 Gold, DebonAir spring, Motion Control damper, tapered steerer, 44 mm offset, Boost110, 15 mm Maxle Stealth, 140 mm travel |
| Rear Suspension | Fox Performance Float EVOL, 3-position DPS damper, tuned by Trek Suspension Lab, 210x55 mm |
| Bottom bracket | SRAM DUB, 92 mm, PressFit |
| Stem | Bontrager Rhythm Comp, 31.8 mm, Knock Block, 0-degree |
| Handlebar | Bontrager alloy, 31.8 mm, 15 mm rise |
| Grips | Bontrager XR Trail Comp, lock-on |
| Brakes | Shimano hydraulic disc, MT400 caliper |
| Brake Levers | Shimano MT401 |
| Rear Derailleur | SRAM NX Eagle, 12-speed |
| Shift Levers | SRAM NX Eagle, 12-speed |
| Cassette | SRAM PG-1230 Eagle, 11-50, 12-speed |
| Chain | SRAM NX Eagle, 12-speed |
| Crankset | SRAM NX Eagle, DUB, 30 T steel ring, Boost |
| Front Wheel | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110 |
| Rear Wheel | Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost148 |
| Tyres | Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 29x2.60" (smaller sizes |
| Saddle | Bontrager Arvada, steel rails |
| Seatpost | TranzX JD-YSP18, 130 mm travel, internal routing, 31.6 mm |
| Weight Limit | 136kg (bike, rider and cargo) |
| Manufacturer Claimed Weight | M - 15.05 kg / 33.19 lbs (with tubes) |
Built, Checked, Tuned and Tested
All our bikes are fully built, checked, tuned and tested by our Cytech qualified mechanics and then securely packaged, ready for delivery. All you have to do is add the pedals (if included), attach the handlebars to the stem and tighten them following the included detailed instructions or by watching our video and using the provided FREE tools. Visit our Bike Assembly page to see how you assemble your new bike once you receive it.
All bikes collected from our shop, are built, tested and ready to ride. For hassle-free home delivery and bike set-up from a qualified mechanic use our Premier Delivery Service.
Please note, occasionally, manufacturers may change the specification without notice. Bicycles do not come with pedals unless otherwise specified. Bikes ordered for delivery will not arrive with the pedals installed, please refer to the owners manual and pedal installation guides provided for guidance. We do not install accessories to bikes, including mudguards. Bikes ordered for delivery that have tubeless compatible tyres and rims will arrive with inner tubes installed or with tubeless valves installed, this will be brand dependent. Sealant is available to be purchased separately.
