Checkmate SLR 7 Force AXS XPLR Gravel Bike

Sale

Final Few

Sale

Final Few

Trek

Trek Checkmate SLR 7 Force AXS XPLR Gravel Bike

£5,225.00

£7,000.00

Save 25%

Delivery

Select size to see delivery options

Collect in Store

Cycle to Work – Save up to 42%

Spread the cost of your new bike and save up to 42% through the Cycle to Work scheme. We accept all major providers including Cyclescheme, Green Commute Initiative, Bike2Work and more. Check with your employer for eligibility.

Free Delivery on all bikes

Complimentary standard delivery on all bikes to UK mainland addresses. Orders typically arrive within 2–5 working days. A signature is required on delivery. When you receive your bike all you'll need to do is unpack it, attach your pedals, turn the handlebars and ride.

Premier Delivery

Upgrade to Premier Delivery at checkout for a nominated day, extended assembly and in-home handover by a trained technician. Available on eligible bikes across UK mainland.

Built, checked, tuned & tested

All our bikes are fully built, checked, tuned and tested by our Cytech qualified mechanics and then securely packaged, ready for delivery. All you have to do is add the pedals (if included), attach the handlebars to the stem and tighten them following the included detailed instructions or by watching our video and using the provided FREE tools. Visit our Bike Assembly page to see how you assemble your new bike once you receive it.

All bikes collected from our shop, are built, tested and ready to ride.

Pedals & accessories

Please note, occasionally, manufacturers may change the specification without notice. Bicycles do not come with pedals unless otherwise specified. Bikes ordered for delivery will not arrive with the pedals installed, please refer to the owners manual and pedal installation guides provided for guidance. We do not install accessories to bikes, including mudguards. Bikes ordered for delivery that have tubeless compatible tyres and rims will arrive with inner tubes installed or with tubeless valves installed, this will be brand dependent. Sealant is available to be purchased separately.

If you require any assistance please contact our Customer Care team

You May Also Need

Oakley
Jawbreaker Sunglasses - with Prizm Black + Clear Lenses
£145.00
£220.00
Trek
RSL Aero Water Bottle and Carbon Bottle Cage
£62.00
£90.00
Topeak
E-Booster Digital Inflator Electric Pump
£69.00
£99.99

Product Details

Trek Checkmate SLR 7 Force AXS XPLR Gravel Bike

The Trek Checkmate SLR 7 Force AXS XPLR Gravel Bike is a carbon gravel race machine engineered for speed and control on demanding courses. Designed to excel on rough and rolling terrain, it pairs a lightweight aerodynamic frame with IsoSpeed decoupling to smooth out bumps and reduce fatigue over long efforts.

The new Gravel Race geometry keeps the rider in an aggressive, efficient position, ready to respond to every attack without wasting energy. A SRAM Force XPLR AXS E1 wireless drivetrain delivers precise shifting, while carbon wheels and the Trek Aero RSL integrated bar and stem complete a performance-focused build that is light, fast and responsive.

Ideal for riders who want to push their limits on gravel races and epic adventure rides.

Features

Frame: 800 Series OCLV Carbon, IsoSpeed, hidden mudguard mounts, integrated frame bag mounts, RCS Headset System, invisible cable routing, T47, flat-mount disc, integrated chainkeeper, removable front derailleur hanger, UDH, 142x12 mm chamfered thru axle
Fork: Checkmate SLR full carbon, tapered carbon steerer, hidden mudguard mounts, flat-mount disc, 12x100 mm thru axle
Maximum total weight limit (bike, rider, and cargo): 125 kg (275 lb)
Battery: SRAM eTap battery pack (with charger)
Shifter: SRAM Force AXS, 13-speed
Rear Derailleur: SRAM Force XPLR AXS, 46T max cog
Crankset:
Size XS, S: SRAM Force XPLR with AXS Power Meter, 42T, DUB Wide, 165 mm length
Size M, ML: SRAM Force XPLR with AXS Power Meter, 42T, DUB Wide, 170 mm length
Size L, XL: SRAM Force XPLR with AXS Power Meter, 42T, DUB Wide, 172.5 mm length
Bottom Bracket: SRAM DUB Wide, T47 threaded, internal bearing
Cassette: SRAM Force XPLR XG-1371, 10-46, 13-speed
Chain: SRAM Force E1, 12/13-speed
Front Wheel: Bontrager Aeolus Pro 3V, OCLV Carbon, Tubeless Ready, 25 mm rim width, 100x12 mm thru axle
Rear Wheel: Bontrager Aeolus Pro 3V, OCLV Carbon, Tubeless Ready, 25 mm rim width, SRAM XD-R driver, 142x12 mm thru axle
Skewers: Bontrager Switch chamfered thru axle, removable lever
Tyres: Bontrager Girona RSL, Tubeless Ready, GR puncture protection, aramid bead, 220 tpi, 700x42 mm
Tyre Sealant: Bontrager TLR sealant, 180 ml (6 oz)
Rim Strip: Bontrager TLR
Max Tyre Size: 45 mm without mudguards, 38 mm with mudguards (as measured; see manual for details)
Saddle: Bontrager Aeolus Pro, carbon rails, 145 mm width
Seatpost: KVF aero carbon seat post, 5 mm offset, 280 mm length
Integrated Handlebar/Stem:
Size XS: Trek Aero RSL Road, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 37 cm control width, 40 cm drop width, 70 mm stem
Size S: Trek Aero RSL Road, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 39 cm control width, 42 cm drop width, 80 mm stem
Size M: Trek Aero RSL Road, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 39 cm control width, 42 cm drop width, 90 mm stem
Size ML, L: Trek Aero RSL Road, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 41 cm control width, 44 cm drop width, 100 mm stem
Size XL: Trek Aero RSL Road, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 41 cm control width, 44 cm drop width, 110 mm stem
Handlebar Tape: Trek EcoTack
Brake Rotors: CentreLock, 160 mm

Highlights

Force AXS E1 XPLR Groupset
Frame/Fork: 800 Series OCLV Carbon, IsoSpeed
Bontrager Aeolus Pro 3V, OCLV Carbon Wheelset

Specifications

Model: Checkmate SLR 7 Force AXS XPLR
Battery [Maker]: SRAM
Bottom Bracket [Maker]: SRAM
Bottom Bracket Standard: T47
Brakes [Kind]: Hydraulic Disc
Brakes [Maker]: SRAM
Brakes [Model]: Force AXS
Cassette [Gearing]: 10-46
Cassette [Maker]: SRAM
Cassette [Model]: Force XPLR XG-1371
Chain [Maker]: SRAM
Chain [Model]: Force E1
Chainring [Gearing]: 42
Crank [Maker]: SRAM
Crank [Model]: Force XPLR
Discipline Compatibility: Gravel
E-Bike: No
F Hub [Maker]: Bontrager
F Hub [Model]: Aeolus Pro 3V
Family: Checkmate
Fenders Mounts: Yes
Fork [Axle Diameter]: 12 mm
Fork [Axle Type]: 12x100mm Thru-Axle
Fork [Brake Type]: Disc
Fork [Maker]: Trek
Fork [Material]: Carbon
Fork [Model]: Checkmate SLR
Fork [Wheel Size]: 700c
Frame [Hanger Standard]: UDH
Frame [Material]: Carbon
Frame [Tire Clearance]: 45c mm
Frameset: No
Gearing [Configuration]: 1x
Gearing [Kind]: Conventional
Gender: Unisex
Handlebar [Drop]: 124 mm
Handlebar [Kind]: Drop
Handlebar [Maker]: Trek
Handlebar [Material]: Carbon
Handlebar [Reach]: 80 mm
Handlebar [Shape]: Drop bar
Headset [Maker]: Trek
Power Meter [Maker]: SRAM
Power Meter [Model]: Force AXS
R Hub [Maker]: SRAM
Rack Mounts: No
RD [Maker]: SRAM
RD [Model]: Force XPLR AXS
Saddle [Maker]: Bontrager
Saddle [Material]: Carbon
Saddle [Width]: 145 mm
Seatpost [Kind]: Aero
Seatpost [Length]: 280 mm
Seatpost [Maker]: Trek
Seatpost [Material]: Carbon
Seatpost [Offset]: 5 mm
Shifters [Maker]: SRAM
Shifters [Model]: Force AXS
Shifting: Electronic
Stem [Maker]: Trek
Stem [Material]: Carbon
Sub Family: Checkmate SLR
Suspension Configuration: Rigid
Tires [Maker]: Bontrager
Tires [Width]: 42 mm
Wheels [Configuration]: Front+Rear
Wheels [Kinds]: Tubeless Ready
Wheelset [Inner Width]: 25 mm
Wheelset [Maker]: Bontrager
Wheelset [Material]: Carbon
Wheelset [Model]: Aeolus Pro 3V
Product code: 1939161 / 54293897347418

Size Guide

	XS	S	M	ML	L	XL
A - Seat Tube (CM)	37.3	41.1	45.5	50	53.7	58.3
B - Seat Tube Angle	73.9°	73.9°	73.7°	73.5°	73.6°	73.7°
C - Head Tube Length (CM)	9.1	10.6	12.6	15	17.4	19.9
D - Head Tube Angle	71.0°	71.3°	71.5°	71.7°	72.0°	72.4°
E - Effective Top Tube (CM)	53.2	54	55.5	57	58.1	59.2
G - Bottom Bracket Drop (CM)	8	8	8	8	8	8
H - Chainstay Length (CM)	42.6	42.6	42.6	42.6	42.6	42.6
I - Offset (CM)	4.9	4.9	4.9	4.9	4.9	4.9
J - Trail (CM)	7.2	7	6.8	6.7	6.5	6.2
K - Wheelbase (CM)	100.3	101.1	102.2	103.5	104.5	105.4
L - Standover (CM)	71.8	74.7	78.2	81.6	85.1	88.6
M - Reach (CM)	38	38.5	39.2	39.9	40.4	40.9
N - Stack (CM)	52.5	54	56	58.4	60.8	63.3
