Trek

Trek Checkout SL 7 AXS Gravel Bike

£6,500.00

The Trek CheckOUT SL 7 Gravel Bike features a carbon frame with 55 mm of rear travel via a RockShox SIDluxe IsoStrut shock, built for tackling gravel, singletrack, and demanding trails beyond smooth roads.

Delivery

Select size to see delivery options

Collect in Store

Cycle to Work – Save up to 42%

Spread the cost of your new bike and save up to 42% through the Cycle to Work scheme. We accept all major providers including Cyclescheme, Green Commute Initiative, Bike2Work and more. Check with your employer for eligibility.

Free Delivery on all bikes

Complimentary standard delivery on all bikes to UK mainland addresses. Orders typically arrive within 2–5 working days. A signature is required on delivery. When you receive your bike all you'll need to do is unpack it, attach your pedals, turn the handlebars and ride.

Premier Delivery

Upgrade to Premier Delivery at checkout for a nominated day, extended assembly and in-home handover by a trained technician. Available on eligible bikes across UK mainland.

Built, checked, tuned & tested

All our bikes are fully built, checked, tuned and tested by our Cytech qualified mechanics and then securely packaged, ready for delivery. All you have to do is add the pedals (if included), attach the handlebars to the stem and tighten them following the included detailed instructions or by watching our video and using the provided FREE tools. Visit our Bike Assembly page to see how you assemble your new bike once you receive it.

All bikes collected from our shop, are built, tested and ready to ride.

Pedals & accessories

Please note, occasionally, manufacturers may change the specification without notice. Bicycles do not come with pedals unless otherwise specified. Bikes ordered for delivery will not arrive with the pedals installed, please refer to the owners manual and pedal installation guides provided for guidance. We do not install accessories to bikes, including mudguards. Bikes ordered for delivery that have tubeless compatible tyres and rims will arrive with inner tubes installed or with tubeless valves installed, this will be brand dependent. Sealant is available to be purchased separately.

If you require any assistance please contact our Customer Care team

You May Also Need

Trek
Town Double Pannier Set 17L
£60.00
£80.00
RockShox
Reverb AXS XPLR Dropper Seatpost
£445.00
£500.00
Specialized
Diverge 4 Expert GRX Di2 Gravel Bike
£4,199.00
£5,499.00

Product Details

Checkout SL 7 Force AXS Gravel Bike

The Trek CheckOUT SL 7 Gravel Bike is designed for riders who want to push beyond smooth roads and take on rough gravel, singletrack and demanding trails. Its carbon frame delivers 55 mm of rear travel through a RockShox SIDluxe IsoStrut shock.

Trek's smooth performance

At the front, a RockShox Rudy XL fork with 60 mm of travel helps tame uneven ground and keeps the ride stable and controlled across challenging terrain.

Trek Checkout's premium upgrades

This model is fitted with Bontrager Aeolus Pro 3V carbon wheels, a SRAM Force AXS E1 wireless 13 speed drivetrain and a RockShox Reverb AXS wireless dropper post, providing top end performance for serious gravel exploration.

Features

Frame:
500 Series OCLV Carbon, integrated frame bag mounts, integrated rack, T47, UDH, 142x12 mm chamfered thru axle, 55 mm travel
Fork:
RockShox Rudy XL Ultimate, Charger Race Day 2 Solo Air spring, tapered steerer, 45 mm offset, 12x100 mm thru axle, 60 mm travel
Weight limit: This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb)
Battery: SRAM AXS battery pack (with charger)
Rear Derailleur: SRAM X0 Eagle AXS, T-Type
Cassette: SRAM Eagle XS-1295, T-Type, 10-52, 12-speed
Chain: SRAM X0 Eagle, T-Type, 12-speed
Max chainring size: 1x: 38T
Front Wheel: Bontrager Aeolus Pro 3V, OCLV Carbon, Tubeless Ready, 25 mm rim width, 100x12 mm thru axle
Rear Wheel: Bontrager Aeolus Pro 37V, OCLV Carbon, Tubeless Ready, 25 mm rim width, SRAM XD-R driver, 142x12 mm thru axle
Rear Skewer: Bontrager Switch chamfered thru axle, removable lever
Tyre: Bontrager Betasso RSL GX, Tubeless Ready, aramid bead, 60 tpi, 700x50 mm
Tyre Part: Bontrager TLR sealant, 180 ml / 6 oz
Saddle: Verse Short Elite, hollow magnesium rails, 145 mm width
Seatpost: RockShox Reverb AXS, 100 mm travel, wireless, 31.6 mm, 337 mm length
Handlebar:
Size - S: Bontrager GR Checkout, 42 cm
Size - M: Bontrager GR Checkout, 44 cm
Size - L, ML: Bontrager GR Checkout, 46 cm
Size - XL: Bontrager GR Checkout, 48 cm
Handlebar Tape: Bontrager Supertack Perf tape
Stem:
Size - S, M: Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length
Size - L, ML: Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length
Size - XL: Bontrager Pro, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length
Rotor Size: Max brake rotor sizes 180 mm front and rear

Specifications

Model: CheckOUT SL 7
Bottom Bracket [Maker]: SRAM
Bottom Bracket Standard: T47
Brakes [Kind]: Hydraulic Disc
Brakes [Maker]: SRAM
Cassette [Gearing]: 10-52
Cassette [Maker]: SRAM
Cassette [Model]: Eagle XS-1295
Chain [Maker]: SRAM
Chain [Model]: X0 Eagle
Chainring [Gearing]: 38
Crank [Maker]: SRAM
Crank [Model]: Force 1 XPLR E1
Discipline Compatibility: Gravel
E-Bike: No
Family: CheckOUT SL
Fork [Axle Diameter]: 12 mm
Fork [Axle Type]: Thru-Axle
Fork [Brake Type]: Disc
Fork [Maker]: RockShox
Fork [Material]: Carbon
Fork [Model]: Rudy XL Ultimate
Fork [Rake]: 45 mm
Fork [Travel]: 60 mm
Fork [Wheel Size]: 700c
Frame [Hanger Standard]: UDH
Frame [Material]: Carbon
Frame [Tire Clearance]: 50c mm
Frame [Travel]: 55 mm
Frameset: No
Gearing [Configuration]: 1x
Gearing [Kind]: Conventional
Gender: Unisex
Handlebar [Kind]: Drop
Handlebar [Maker]: Bontrager
Handlebar [Material]: Carbon
Handlebar [Reach]: 70 mm
Handlebar [Shape]: Drop bar
Rack Mounts: Yes
RD [Maker]: SRAM
RD [Model]: X0 Eagle AXS
Rear Shock [Maker]: RockShox
Rear Shock [Model]: SIDluxe Ultimate
Saddle [Maker]: Bontrager
Saddle [Material]: Steel
Saddle [Width]: 145 mm
Seatpost [Diameter]: 31.6
Seatpost [Kind]: Dropper
Seatpost [Length]: 337 mm
Seatpost [Maker]: RockShox
Shifters [Maker]: SRAM
Shifters [Model]: Force AXS E1
Shifting: Electronic
Stem [Angle]: 7 degree
Stem [Clamp Diameter]: 31.8
Stem [Maker]: Bontrager
Stem [Material]: Aluminium
Suspension Configuration: Full Suspension
Tires [Maker]: Bontrager
Tires [Width]: 50 mm
Wheels [Configuration]: Front+Rear
Wheels [Kinds]: Tubeless Ready
Wheelset [Inner Width]: 25 mm
Wheelset [Maker]: Bontrager
Wheelset [Material]: Carbon
Wheelset [Model]: Aeolus Pro 3V
Product code: 1939185 / 54293896855898

Size Guide

—	48	51	54	57	60	63
Rider Height (Cm)	158 - 163	162 - 168	167 - 174	173 - 184	184 - 191	190 - 197
Seat Tube (ctr-top)	440	482	512	543	573	605
Seat Tube (ctr-ctr)	-	-	-	-	-	-
Effective Top Tube	520	531	543	557	583	603
Actual Top Tube	-	-	-	-	-	-
Seat Angle (°)	74.3	74	73.8	73.5	73	72.8
Head Tube Angle (°)	69.5	70	71	71.8	71.8	72.3
Head Tube Length	115	125	14	160	200	320
Fork Rake	52	52	52	52	52	52
Chainstay Length	450	450	450	450	450	450
Wheelbase	1041	1045	1048	1052	1074	1086
Stack	540	551	565	587	625	655
Reach	368	373	378	383	392	400
Tail	74	71	65	59	59	56
Standover	713	741	768	794	826	854

*All measurements in mm unless otherwise stated
