Description
Moulding a sophisticated carbon construction into a highly refined frame silhouette and adding accurate components, the Orbea Orca M20 Disc Road Bike naturally infuses a multifaceted performance that revels in mountain gran fondos, back road excursions and the fastest of chain-gangs.
A high grade of carbon is laid via an intricate format throughout the frame’s tube sections to afford stunning levels of comfort across the roughest of road surfaces and punchy acceleration for climbing and sprinting. This lightweight frame is partnered with a stiff and strong carbon fork that increases comfort and lowers rider fatigue by reducing road vibrations. The already clean aesthetic of the frame is complemented by the internal cable routing that also neatly runs through the stem while the 35mm tyre clearance allows the use of broader, plusher and quicker rolling tyres. A race-inspired geometry crowns the frame by instilling reactivity and poise and also puts the rider in the perfect position from an ergonomic perspective for efficient and durable power transfer.
Light but strong alloy wheels are low maintenance and fast and are driven by the ultra-reliable and precise Shimano Ultegra 11-speed gear configuration. Confidence-inspiring stopping power, even when enduring wet mountain descents is gifted by the full hydraulic disc brakes that are also from the well respected Ultegra stable.
Frame | Orbea Orca carbon OMR Disc, monocoque construction, 1,5” headset, BB 386 bottom bracket standard, power meter compatible, 12x142mm rear thru-axle with M12x2 P1 thread, speed release compatible dropout, internal cable routing, EC/DC compatible |
Fork | Orbea carbon fork 2021, 1-1/8” aluminium steerer |
Headset | Acros alloy 1-1/2" internal cable routing |
Stem | Orbea OC1 31.8mm interface 6-degree (Length 90mm Size 47 / 100mm Sizes 49, 51 / 110mm Sizes 53, 55, 57 / 120mm Size 60) |
Handlebar | Orbea OC1 Road, reach 80mm, drop 125mm (Width (C-C) 400mm Sizes 47, 49 / 420mm Sizes 53, 55, 57 / 440mm Sizes |
Front Brake | Shimano Ultegra R8070, hydraulic disc |
Rear Brake | Shimano Ultegra R8070, hydraulic disc |
Brake Levers | Shimano Ultegra R8070, hydraulic disc |
Front Derailleur | Shimano Ultegra R8000 |
Rear Derailleur | Shimano Ultegra R8000 GS, 11-speed |
Shift Levers | Shimano Ultegra ST-8020, 11-speed |
Chain | KMC X11-EL, 11-speed |
Cassette | Shimano 105 R7000 11-30t, 11-speed |
Crankset | Shimano Ultegra R8000, 34x50 teeth chainrings (Length 170mm Sizes 47, 49, 51, 53 / 172.5mm Sizes 55, 57 / 175mm Size 60) |
Front Wheel | Orbea Ready 19, 12mm E-Thru hub Shimano RS470 28H with Orbea thru-axle 12x100mm M12x2 P1, solid |
Rear Wheel | Orbea Ready 19, 12mm E-Thru hub Shimano RS470 28H with Orbea thru-axle 12x142mm M12x2 P1, solid |
Front Tyre | Vittoria Zafiro V Rigid bead 700x28c, clincher |
Rear Tyre | Vittoria Zafiro V Rigid bead 700x28c, clincher |
Saddle | Selle Royal Seta RS |
Seatpost | Orbea OC2 27.2mm diameter, 20mm offset |
Pedals | Available to be purchased separately |
All our bikes are fully built, checked, tuned and tested by our Cytech qualified mechanics and then securely packaged, ready for delivery. All you have to do is add the pedals (if included), attach the handlebars to the stem and tighten them following the included detailed instructions or by watching our video and using the provided FREE tools. Visit our Bike Assembly page to see how you assemble your new bike once you receive it.
All bikes collected from our shop, are built, tested and ready to ride. For hassle-free home delivery and bike set-up from a qualified mechanic use our Premier Delivery Service.
Please note, occasionally, manufacturers may change the specification without notice. Bicycles do not come with pedals unless otherwise specified. Bikes ordered for delivery will not arrive with the pedals installed, please refer to the owners manual and pedal installation guides provided for guidance. We do not install accessories to bikes, including mudguards. Bikes ordered for delivery that have tubeless compatible tyres and rims will arrive with inner tubes installed or with tubeless valves installed, this will be brand dependent. Sealant is available to be purchased separately.
