Orbea Vibe H30 Electric Hybrid Bike 2023
The Orbea Vibe H30 Electric Hybrid Bike is a great choice for discerning commuters and leisure riders seeking a purposeful and stylish ride. Integrated cabling provides a sleek and clean look, while the slimline 248Wh battery is nestled neatly into the downtube to offer a traditional, non-electric aesthetic.
Controllable via the Mahle iWoc TRIO remote situated on the top tube, the Mahle X35 Plus motor is contained within the rear hub, helping you cruise up any hill and provide assistance up to a maximum speed of 15.5mph / 25kph. The Magura MT30 hydraulic brakes provide efficient stopping power, and the 10-speed Shimano Deore drivetrain offers crisp shifting and a wide gear range. The Kenda tyres are reflective and feature a puncture-resistant strip, and they're fitted to strong, durable wheels.
Browse our range of Orbea electric hybrid bikes today.
Highlights
- Integrated frame lighting
- Lightweight internal Mahle 36V/6.9A 248Wh ANT+ battery
- Mahle X35 Plus hub motor system
- Minimalist and integrated design to mimic the look of a manual bike
- Near drag-free pedalling when the motor is not in use
- Discreet Mahle iWoc TRIO handlebar remote
- 10-speed Shimano Deore groupset for smooth shifting
- Powerful hydraulic Magura MT30 hydraulic disc brakes
Battery Specifications
- Maximum Assist: 250w / 40Nm torque
- Battery Power: 248wh
Technical Specification
| Frame | Orbea Vibe Top Bar Hydro 6061 Hydroform Aluminium 2021, ICR cable routing, Forged BB, 135x9 QR, flat mount disc, 700x45 maximum tyre clearance, 1" 1/2 semi headset, 41x86.5 Pressfit BB, carrier and mudguard compatible |
| Fork | Orbea Vibe carbon fork, full carbon, 1-1/5, 700x45 maximum tyre clearance, flat mount disc mount, thru-axle 12x100mm, long mudguard compatible |
| Headset | Orbea Acros Alloy 1-1/2" Internal Cable Routing |
| Stem | Orbea-approved alloy forged, -6º, ICR |
| Handlebar | Orbea-approved alloy 31.8mm, 12mm rise, 700mm |
| Front Brake | Magura MT30 Hydraulic Disc Easy Route Connection |
| Rear Brake | Magura MT30 Hydraulic Disc Easy Route Connection |
| Brake Levers | Magura |
| Rear Derailleur | Shimano Deore M5120 SGS Shadow Plus, 10-speed |
| Shift Levers | Shimano Deore M4100, 10-speed |
| Chain | KMC X10 |
| Cassette | Shimano CS-M4100, 11-46t, 10-speed |
| Crankset | Orbea-approved forged alloy, 42t, with chainguard |
| Front Wheel | Orbea-approved alloy, tubeless, 700x21c, 32H |
| Rear Wheel | Orbea-approved alloy, tubeless, 700x21c, 32H, Mahle motor hub X35 Plus |
| Front Tyre | Kenda K1052 700x45C Reflective type, clincher |
| Rear Tyre | Kenda K1052 700x45C Reflective type, clincher |
| Saddle | Selle Royal Lift 1215 URN 278x145mm |
| Seatpost | Orbea Alloy 27.2, setback 0mm, for integrated light |
| Pedals | VP-537 Black |
| Motor | Mahle motor hub X35 Plus, 250w, 40Nm |
| Remote | Mahle iWoc TRIO |
| Battery | Mahle 36V/6.9A 248Wh ANT+ |
| Charger | Mahle X35 |
| Accessories | Front position light, on head tube, COB Led, On/Off, 60 Lumen, ECE50 / Lezyne FENDER STVZO 11 lumens rear light / Knog OI Classic bell |
| Electric assisted speed limit | 15.5mph / 25kph |
Built, Checked, Tuned and Tested
All our bikes are fully built, checked, tuned and tested by our Cytech qualified mechanics and then securely packaged, ready for delivery. All you have to do is add the pedals (if included), attach the handlebars to the stem and tighten them following the included detailed instructions or by watching our video and using the provided FREE tools. Visit our Bike Assembly page to see how you assemble your new bike once you receive it.
All bikes collected from our shop, are built, tested and ready to ride.
Please note, occasionally, manufacturers may change the specification without notice. Bicycles do not come with pedals unless otherwise specified. Bikes ordered for delivery will not arrive with the pedals installed, please refer to the owners manual and pedal installation guides provided for guidance. We do not install accessories to bikes, including mudguards. Bikes ordered for delivery that have tubeless compatible tyres and rims will arrive with inner tubes installed or with tubeless valves installed, this will be brand dependent. Sealant is available to be purchased separately.
