Trek Marlin 8 Mountain Bike 2022

★★★★★ ★★★★★
(0)
£900.00

Select a colour and size to view stock availability

Find My Size
Trek
Marlin 8 Mountain Bike 2022

We're sorry, but unfortunately, we're unable to ship this item to your country

Product ID: 1416731

Why buy your bike from Sigma Sports?

sigma sports expert advice
Expert Advice

Don't hesitate to reach out to us. It's our goal to answer all of your questions and offer the best advice from our experts. We’ll be happy to answer any questions you may have. Contact us now or visit us in-store.

sigma sports built checked tuned and tested
Built, Checked, Tuned and Tested

All our bikes are fully built by our Cytech qualified mechanics. To find out more, see the Built, Checked, Tuned and Tested section below to see how we'll deliver your bike.

Free Bike Delivery

We offer FREE DELIVERY of your bike to your home or place of work. Once you've placed your order, our Customer Care team will be in contact to offer a convenient delivery date of your choice.

sigma sports cycle to work scheme
Cycle to Work Scheme

Cyclescheme can save you up to 39% on a bike and accessories. Visit our Cycle to Work Scheme page to learn more and claim.

Trek Marlin 8 Mountain Bike 2022

The Trek Marlin 8 Mountain Bike delivers hardtail XC performance at great value. This race-ready bike brings together a strong aluminium frame, light Rockshox fork and reliable components, and is designed with size-specific geometry and features to ensure every rider benefits from the same feel and handling. The RockShox Judy Silver fork incorporates a Solo Air spring that makes it easy to fine-tune for different rider weights, and TurnKey lockout means you can roll faster when the trails are smooth or you hit sections of tarmac.

The SRAM SX Eagle 1x12-speed drivetrain offers a wide range of gears, getting you up the steepest hills, and shifting is smooth and precise. Shimano hydraulic disc brakes take care of stopping and work well in all conditions - dry, wet or muddy. Cables are routed internally for a clean aesthetic and reduced risk of contamination, making for easier maintenance. The tubeless-ready Bontrager Kovee wheels are frame size-specific, ranging from 26" to 29", for better control across the board, with the two smallest sizes also having a curved top tube and lower standover height.

Highlights

  • Lightweight aluminium frame
  • RockShox Judy Silver fork with a Solo Air spring and TurnKey hydraulic lockout
  • SRAM SX Eagle 1x12-speed drivetrain
  • Shimano hydraulic disc brakes
  • Tubeless-ready Bontrager Kovee wheels
  • Marlin models in XXS to S frame sizes have a curved top tube and a lower standover height that makes it easier for smaller riders to mount and dismount
  • Rack and kickstand mounts

Technical Specification

Frame Trek Alpha Silver Aluminium, internal routing, chainstay disc-brake mount, rack and kickstand mount, 135x5mm QR
Fork RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 100mm QR, 80mm travel (size XXS, XS) / 100mm travel (size (S - XXL)
Headset Semi-integrated, 1-1/8"
Bottom Bracket Truvativ Powerspline, 73mm, threaded cartridge, 118mm spindle
Stem Bontrager alloy, 31.8mm, Blendr compatible, 7-degree, length - 35mm (XXS) / 50mm (XS) / 60mm (S) / 70mm (M) / 80mm (ML, L) / 90mm (XL, XXL)
Handlebar Bontrager alloy, 31.8mm, 5mm rise, width - 690mm (XXS, XS) / 720mm (S - XXL)
Grips Bontrager XR Trail Comp, nylon lock-on
Front Brake Shimano MT200 hydraulic disc, rotor - RT26, 6-bolt, 160mm (XXS - ML) / 180mm (L - XXL)
Rear Brake Shimano MT200 hydraulic disc, rotor - RT26, 6-bolt, 160mm (XXS - ML) / 180mm (L - XXL)
Brake Levers Shimano MT200
Rear Derailleur SRAM SX Eagle, 12-speed
Shift Levers SRAM SX Eagle, 12-speed
Chain SRAM SX Eagle, 12-speed
Cassette SRAM PG-1210 Eagle, 11-50t, 12-speed
Crankset SRAM SX Eagle, 30T steel ring (49mm chainline), length - 155mm (XXS) / 170mm (XS - M) / 175mm (ML - XXL)
Front Wheel Hub - Formula DC-20 LW, alloy, 6-bolt, 5x100mm QR / rim - Bontrager Kovee, double-wall, tubeless-ready, 28-hole, 23mm width, Presta valve / spokes - 14-gram stainless steel
Rear Wheel Hub - Formula DC-22LW, 6-bolt, Shimano 8/9/10 freehub, 135x5mm QR / rim - Bontrager Kovee, double-wall, tubeless-ready, 28-hole, 23mm width, Presta valve / spokes - 14-gram stainless steel
Front Tyre Maxxis Ardent Race, tubeless, EXO casing, folding bead, 60 tpi, size - 26x2.40" (XXS) / 27.5x2.35" (XS, S) / 29x2.35" (M - XXL)
Rear Tyre Maxxis Ardent Race, tubeless, EXO casing, folding bead, 60 tpi, size - 26x2.40" (XXS) / 27.5x2.35" (XS, S) / 29x2.35" (M - XXL)
Saddle Bontrager Arvada, steel rails, 138mm width
Seatpost Bontrager alloy, 31.6mm, 12mm offset, length - 300mm (XXS) / 330mm (XS - M) / 400mm (ML - XXL)
Pedals Available to be purchased separately
Manufacturer Claimed Weight 13.2kg / 29.1lbs (M)

Built, Checked, Tuned and Tested

All our bikes are fully built, checked, tuned and tested by our Cytech qualified mechanics and then securely packaged, ready for delivery. All you have to do is add the pedals (if included), attach the handlebars to the stem and tighten them following the included detailed instructions or by watching our video and using the provided FREE tools. Visit our Bike Assembly page to see how you assemble your new bike once you receive it.

All bikes collected from our shop, are built, tested and ready to ride.

Please note, occasionally, manufacturers may change the specification without notice. Bicycles do not come with pedals unless otherwise specified. Bikes ordered for delivery will not arrive with the pedals installed, please refer to the owners manual and pedal installation guides provided for guidance or contact Customer Care. We do not install accessories to bikes, including mudguards.


Trek Marlin 8 Mountain Bike 2022 Sizing
